| Model |
Liugong CLG922D |
| Type |
Hydraulic Crawler Excavator |
| Operating Weight |
22,000 kg |
| Standard Bucket Capacity (Heaped) |
1.0 m³ (Range:0.73~1.1 m³) |
| Boom Length |
5680 mm |
| Arm Length |
2910 mm |
| Shipping Dimension(L×W×H) |
9690 × 2990 × 3050 mm |
| Track Shoe Width |
600 mm |
| Track Gauge |
2390 mm |
| Ground Pressure |
45.6 kPa |
| Travel Speed |
2.9 ~ 4.9 km/h |
| Gradeability |
70% |
| Swing Speed |
12 rpm |
| Bucket Breakout Force (ISO) |
159 kN |
| Arm Breakout Force (ISO) |
103 kN |
| Max Dig Depth |
6615 mm |
| Max Reach at Ground Level |
9705 mm |
| Max Dig Height |
9540 mm |
| Max Dump Height |
6770 mm |
| Engine |
Cummins 6BTAA5.9-C |
| Rated Power |
112 kW @1950 rpm |
| Displacement |
5.9 L, 6 Cylinders, Turbocharged |
| Fuel Tank Capacity |
412 L |
| Hydraulic Tank Capacity |
230 L |
| Total Hydraulic System Volume |
330 L |
| Main Pump |
Dual variable axial piston pump |
| Main Pump Total Flow |
420 L/min |
| Main Relief Pressure |
31.8 MPa |
