| Caterpillar 313D2 GC Technical Specifications Table | |||
| Parameter Category | Item | Specification | Notes |
| Basic Information | Model | 313D2 GC | |
| Tonnage Class | 13-ton | ||
| Operating Weight | 13,200 kg – 13,500 kg | Varies by configuration | |
| Bucket Capacity | 0.10 – 0.53 m³ | Common configuration ~0.52 m³ | |
| Engine | Model | Caterpillar C4.4 | |
| Type | Turbocharged, Direct Injection, Water-cooled Diesel Engine | ||
| Rated Power | 70 kW / 94 HP | Per ISO Standards | |
| Emission Standard | Meets China National III / EU Stage IIIA | ||
| Hydraulic System | Hydraulic System Type | Load Sensing System | |
| Main Pump Type | Variable Displacement Axial Piston Pump | ||
| Main Pump Max. Flow | 2 x 124 L/min | ||
| Main Relief Valve Pressure | 34.3 MPa | ||
| Dimensions | Transport Length | 8,660 mm | |
| Transport Width | 2,490 mm | With 600mm shoe | |
| Transport Height | 2,840 mm | To boom hinge | |
