| Caterpillar 320D Technical Specifications Table | |||
| Parameter Category | Item | Specification | Notes / Explanation |
| Basic Information | Model | 320D | |
| Operating Weight | 19,700 kg – 20,600 kg | Varies by configuration | |
| Bucket Capacity | 0.60 – 1.25 m³ | Common configuration ~0.8 – 1.0 m³ | |
| Engine | Model | Caterpillar C6.4 ACERT | |
| Type | Turbocharged, Aftercooled, Electronically Controlled Diesel Engine | ||
| Rated Power | 103 kW / 138 HP | ||
| Displacement | 6.4 L | ||
| Emission Standard | Meets Tier 3 / EU Stage IIIA | ||
| Hydraulic System | Hydraulic System Type | Load Sensing System | |
| Main Pump Type | Variable Displacement Axial Piston Pump | ||
| Main Pump Max. Flow | 2 x 202 L/min | ||
| Main Relief Valve Pressure | 34.8 MPa | ||
| Dimensions | Length | 9,540 mm | |
| Width | 2,800 mm | With 700mm shoe | |
| Height | 3,150 mm | To top of cab | |
