| Model |
LiuGong 913EG4 |
| Machine Type |
Crawler Hydraulic Excavator |
| Operating Weight |
13500 kg |
| Standard Bucket Capacity (Heaped) |
0.55 m³ |
| Boom Length |
4600 mm |
| Arm Length |
2500 mm |
| Engine |
Cummins F4.5, 4-cylinder turbocharged, high-pressure common rail diesel |
| Emission Standard |
China Stage IV (国四) |
| Rated Power |
89 kW (119 HP) @ 2200 rpm |
| Max Torque |
500 N·m @1300~1700 rpm |
| Displacement |
4.5 L |
| Cooling System |
Water cooling |
| Working Range |
|
| Max Digging Reach |
8300 mm |
| Max Digging Depth |
5470 mm |
| Max Cutting Height |
8760 mm |
| Max Dumping Height |
6310 mm |
| Max Vertical Wall Digging Depth |
4770 mm |
| Min Front Swing Radius |
2470 mm |
| Digging Force (ISO) |
|
| Bucket Digging Force |
89.8 kN |
| Arm Digging Force |
64.9 kN |
| Swing Speed |
12 rpm |
| Travel Speed (Low / High) |
3.2 km/h / 5.0 km/h |
| Max Drawbar Pull |
122 kN |
| Gradeability |
70% (35°) |
| Ground Pressure |
41.5 kPa |
| Hydraulic System |
|
| Main Pump |
Variable axial piston pump |
| Main Relief Pressure |
34.3 MPa |
| Track Shoe Width (Standard) |
500 mm |
| Transport Dimensions |
|
| Overall Shipping Length |
7750 mm |
| Overall Shipping Width |
2490 mm |
| Overall Shipping Height (ROPS Cab) |
2940 mm |
| Service Capacities |
|
| Fuel Tank |
245 L |
| Hydraulic Oil Tank |
130 L |
