| Model |
LiuGong CLG913E |
| Machine Type |
Crawler Hydraulic Excavator |
| Operating Weight |
13500 kg |
| Standard Bucket Capacity (Heaped) |
0.58 m³ (Optional: 0.36~0.58 m³) |
| Boom Length |
4600 mm |
| Arm Length |
2500 mm |
| Engine |
Cummins QSF3.8, 4-cylinder turbocharged & intercooled diesel |
| Emission Standard |
Tier3 / Stage IIIA |
| Rated Power |
74 kW (99 HP / 101 PS) @ 2200 rpm |
| Max Torque |
420 N·m |
| Displacement |
3.8 L |
| Working Range |
|
| Max Digging Reach |
8300 mm |
| Max Digging Depth |
5470 mm |
| Max Cutting Height |
8760 mm |
| Max Dumping Height |
6310 mm |
| Max Vertical Wall Digging Depth |
4770 mm |
| Min Front Swing Radius |
2470 mm |
| Digging Force (ISO) |
|
| Bucket Digging Force |
89.8 kN |
| Arm Digging Force |
64.9 kN |
| Swing Speed |
12 rpm |
| Travel Speed (Low / High) |
3.2 km/h / 5.0 km/h |
| Drawbar Pull |
132 kN |
| Gradeability |
70% (35°) |
| Ground Pressure |
41.5 kPa |
| Hydraulic System |
|
| Max Pump Flow |
240 L/min |
| Main Relief Pressure |
34.3 MPa |
| Track Shoe Width (Standard) |
500 mm |
| Transport Dimensions |
|
| Overall Shipping Length |
7750 mm |
| Overall Shipping Width |
2490 mm |
| Overall Shipping Height (ROPS Cab) |
2930 mm |
| Service Capacities |
|
| Fuel Tank |
245 L |
| Hydraulic Oil Tank |
130 L |
| Engine Oil |
12 L |
| Cooling System |
21 L |
