| Operating Weight |
32420 kg |
| Standard Bucket Capacity |
1.5 m³; Rock bucket optional 1.3 m³ |
| Boom Length |
6500 mm |
| Stick Length |
3900 mm |
| Engine Model |
CAT 3306TA, 6-cylinder water-cooled turbo direct injection |
| Displacement |
10.5 L |
| Rated Net Power (ISO9249) |
165.5 kW (222 hp) @1800 rpm |
| Emission Standard |
Old non-tier, mechanical direct injection engine |
| Main Pump Max Flow |
480 L/min |
| Main System Relief Pressure |
34.3 MPa |
| Swing Speed |
10.0 rpm |
| Swing Torque |
98.0 kN·m |
| Max Traction Force |
295 kN |
| Travel Speed |
3.2 / 4.8 km/h (low / high) |
| Gradeability |
70% (35°) |
| Bucket Digging Force |
215 kN |
| Stick Digging Force |
170 kN |
| Max Digging Reach at Ground Level |
11620 mm |
| Max Digging Depth |
8080 mm |
| Max Vertical Digging Depth |
7230 mm |
| Max Dumping Height |
7600 mm |
| Max Digging Height |
10770 mm |
| Overall Transport Length |
11080 mm |
| Overall Transport Width |
3340 mm |
| Overall Transport Height |
3610 mm |
| Cab Height |
3150 mm |
| Tail Swing Radius |
3500 mm |
| Minimum Ground Clearance |
510 mm |
| Track Contact Length |
4040 mm |
| Fuel Tank Capacity |
560 L |
| Hydraulic Tank Capacity |
220 L |
| Total Hydraulic System Volume |
400 L |
| Engine Oil Capacity |
32 L |
| Cooling System Capacity |
45 L |
| Swing Reducer Oil |
12 L |
| Final Drive Oil (each side) |
8 L |
