| Model |
Caterpillar 140G |
| Type |
Motor Grader |
| Operating Weight |
14,100 kg (Standard version, with moldboard, no front dozer / rear ripper) |
| Shipping Dimension(L×W×H) |
8400 × 2600 × 3350 mm |
| Standard Moldboard (Blade) Width |
3660 mm (12ft) |
| Moldboard Height |
610 mm |
| Moldboard Thickness |
19 mm |
| Max Cutting Depth |
610 mm |
| Bank Cut Angle |
20° ~ 90° |
| Circle Rotation |
360° |
| Wheelbase |
6100 mm |
| Minimum Turning Radius |
7100 mm |
| Frame Articulation Angle |
±25° |
| Tire Size |
14.00-24 |
| Engine |
CAT 3306DI, 6 cylinders, turbocharged & intercooled |
| Rated Gross Power |
112 kW (150 hp) @2200 rpm; VHP version 134 kW (180 hp) |
| Max Torque |
680 N·m @1400 rpm |
| Transmission |
CAT Powershift, 6 Forward / 6 Reverse |
| Max Travel Speed Forward |
39 km/h |
| Max Travel Speed Reverse |
29 km/h |
| Hydraulic System |
Open center hydraulic system |
| Main Relief Pressure |
20.7 MPa |
| Fuel Tank Capacity |
320 L |
| Service Brake |
Multi-disc oil bath brake |
