Hyundai 210W-9s Wheeled Excavator Technical Specifications Table
|
| Parameter Category |
Specification Item |
Detailed Parameters |
Notes/Remarks |
| General Information |
Model |
210W-9s |
|
|
Operating Weight |
19,200 kg |
Standard configuration |
|
Bucket Capacity |
0.3 – 1.2 m³ |
Common configuration approx. 1.0 m³ |
|
Engine Model |
Cummins B6.7 |
|
| Engine System |
Type |
In-line 6-cylinder, Water-cooled, Turbocharged |
|
|
Displacement |
6.7 L |
|
|
Rated Power/Speed |
125 kW / 2,000 rpm |
Approx. 168 HP |
|
Emission Standard |
Meets China National III |
|
| Dimensions |
Overall Length |
8,650 mm |
Working condition |
|
Overall Width |
2,550 mm |
|
|
Overall Height |
3,280 mm |
To top of cab |
|
Wheelbase |
3,350 mm |
|
| Hydraulic System |
Main Pump Type |
Dual Variable Displacement Axial Piston Pumps |
|
|
Main System Working Pressure |
34.3 MPa |
|
|
Arm Digging Force |
75 kN |
|
|
Bucket Digging Force |
105 kN |
|
|
Max. Swing Speed |
12.0 rpm |
|
