| Model |
CAT 320C |
| Machine Type |
Medium Crawler Hydraulic Excavator |
| Operating Weight |
20800 kg (45856 lbs) |
| Engine Model |
Cat 3066 ATAAC, 6-cylinder turbo diesel |
| Rated Net Power (ISO 9249) |
103 kW (138 hp) @1800 rpm |
| Gross Power |
110 kW (147 hp) @1800 rpm |
| Displacement |
6.4 L (390 cu in) |
| Emission Standard |
EU Stage II |
| Standard Bucket Capacity |
1.0 m³ (1.31 yd³) |
| Boom Length |
5700 mm |
| Stick Length |
2900 mm |
| Max Digging Depth |
6650 mm (21.82 ft) |
| Max Reach at Ground Level |
9750 mm (31.99 ft) |
| Max Dumping Height |
6680 mm (21.92 ft) |
| Bucket Digging Force (ISO) |
152 kN |
| Arm Digging Force (ISO) |
116 kN |
| Hydraulic Max Flow (2 pumps) |
205 L/min (54.2 US gal/min) |
| Main Hydraulic Pressure |
34.3 MPa (4980 psi) |
| Swing Speed |
11.0 rpm |
| Travel Speed |
3.2 ~ 5.5 km/h (1.99 ~ 3.42 mph) |
| Fuel Tank Capacity |
320 L (84.5 US gal) |
| Hydraulic Tank Capacity |
145 L |
| Transport Length |
9600 mm (31.50 ft) |
| Transport Width |
2800 mm (9.19 ft) |
| Transport Height |
2950 mm (9.68 ft) |
| Track Shoe Width (Standard) |
600 mm (23.62 in) |
| Rear Swing Radius |
2750 mm |
| Min Ground Clearance |
450 mm |
