| General Information |
Model |
EC60D |
|
|
Operating Weight |
6,000 kg |
Standard configuration |
|
Bucket Capacity |
0.03 – 0.25 m³ |
Common configuration approx. 0.18 m³ |
|
Engine Model |
Volvo D2.6 |
|
| Engine System |
Type |
In-line 3-cylinder, Water-cooled, Turbocharged |
|
|
Displacement |
2.6 L |
|
|
Rated Power/Speed |
43.5 kW / 2,200 rpm |
Approx. 58 HP |
|
Emission Standard |
Meets China National IV |
|
| Dimensions |
Transport Length |
6,150 mm |
Includes bucket and boom |
|
Transport Width |
2,200 mm |
450mm track shoe width |
|
Transport Height |
2,580 mm |
To top of cab |
|
Track Length |
3,150 mm |
|
|
Ground Clearance |
380 mm |
|
| Hydraulic System |
Main Pump Type |
Variable Displacement Axial Piston Pump |
|
|
Main System Working Pressure |
34.3 MPa |
|
|
Arm Digging Force |
32 kN |
|
|
Bucket Digging Force |
44 kN |
|
|
Max. Swing Speed |
13.5 rpm |
