| General Information |
Model |
EC25D |
|
|
Operating Weight |
2,600 kg |
Standard configuration |
|
Bucket Capacity |
0.02 – 0.08 m³ |
Common configuration approx. 0.06 m³ |
|
Engine Model |
Kubota D1105 |
|
| Engine System |
Type |
In-line 3-cylinder, Water-cooled |
|
|
Displacement |
1.123 L |
|
|
Rated Power/Speed |
18.5 kW / 2,200 rpm |
Approx. 24.8 HP |
|
Emission Standard |
Meets China National IV |
|
| Dimensions |
Transport Length |
4,170 mm |
Includes bucket and boom |
|
Transport Width |
1,550 mm |
300mm track shoe width |
|
Transport Height |
2,390 mm |
To top of cab |
|
Track Length |
1,880 mm |
|
|
Ground Clearance |
260 mm |
|
| Hydraulic System |
Main Pump Type |
Variable Displacement Axial Piston Pump |
|
|
Main System Working Pressure |
25.0 MPa |
|
|
Arm Digging Force |
12 kN |
|
|
Bucket Digging Force |
17 kN |
|
|
Max. Swing Speed |
16.5 rpm |
