| Model |
Liugong CLG890H |
| Type |
Articulated Wheel Loader |
| Rated Load |
9,000 kg |
| Operating Weight |
30,600 kg (Standard cab version, with standard bucket) |
| Standard Bucket Capacity (Heaped) |
5.4 m³ (Optional:4.0 ~9.0 m³) |
| Shipping Dimension(L×W×H) |
9352 × 3170 × 3765 mm |
| Wheelbase |
3700 mm |
| Tread Width |
2420 mm |
| Tire Size |
29.5-25, 28PR L-3 |
| Articulation Angle |
38° |
| Min Turning Radius (over tyre) |
6958 mm |
| Bucket Breakout Force |
245 kN |
| Tipping Load (full turn) |
20600 kg |
| Max Dump Clearance |
3330 mm |
| Max Dump Reach |
1479 mm |
| Ground Clearance |
442 mm |
| Total Hydraulic Cycle Time |
11.0 s |
| Engine |
Cummins QSM11 (Tier2 / Stage II for export used machine) |
| Rated Gross Power |
287 kW (390 hp) @1800 rpm |
| Net Power |
273 kW (371 hp) @1800 rpm |
| 6 Cylinders, Turbocharged & Air-to-air intercooled |
|
| Transmission |
ZF Powershift |
| Hydraulic System |
Load sensing hydraulic system, dual variable piston pumps |
| Main Relief Pressure |
26 MPa |
| Fuel Tank Capacity |
420 L |
| Service Brake |
Wet disc brake |
| Parking Brake |
Electro-hydraulic disc brake |
