| Operating Weight |
4920 – 5090 kg (cab version) |
| Standard Bucket Capacity |
0.15 m³; Optional bucket 0.18 m³ |
| Boom Length |
2450 mm |
| Stick Length |
1690 mm |
| Engine Model |
Yanmar 4TNV88, 4-cylinder water-cooled direct injection |
| Displacement |
2.189 L |
| Bore × Stroke |
88 mm × 90 mm |
| Rated Net Power (ISO9249) |
28.2 kW (37.8 hp) @2400 rpm |
| Emission Standard |
US Tier 4 / EU Stage IIIA |
| Main Pump Max Flow |
122 L/min |
| Main System Relief Pressure |
24.5 MPa |
| Swing Speed |
9.4 rpm |
| Swing Torque |
11.2 kN·m |
| Max Traction Force |
40.2 kN |
| Travel Speed |
2.9 / 4.8 km/h (low / high) |
| Gradeability |
58% (30°) |
| Bucket Digging Force |
43.0 kN |
| Stick Digging Force |
29.0 kN |
| Max Digging Reach at Ground Level |
6130 mm |
| Max Digging Depth |
3830 mm |
| Max Vertical Digging Depth |
3120 mm |
| Max Dumping Height |
4220 mm |
| Max Digging Height |
5680 mm |
| Overall Transport Length |
5350 mm |
| Overall Transport Width |
2000 mm (300mm track shoe) |
| Overall Transport Height |
2580 mm |
| Cab Height |
2540 mm |
| Tail Swing Radius |
1020 mm (Ultra-short tail swing) |
| Minimum Ground Clearance |
330 mm |
| Track Contact Length |
2220 mm |
| Track Gauge |
1450 mm |
| Fuel Tank Capacity |
72 L |
| Hydraulic Tank Capacity |
44 L |
| Total Hydraulic System Volume |
70 L |
| Engine Oil Capacity |
7.3 L |
| Cooling System Capacity |
9.2 L |
| Swing Reducer Oil |
2.3 L |
| Final Drive Oil (each side) |
1.2 L |
