| Operating Weight |
38100 kg (standard) / 40200 kg (340DL long track, 600mm track shoe) |
| Standard Bucket Capacity |
2.1 m³; Heavy-duty rock bucket optional 1.8 m³ |
| Boom Length |
6700 mm |
| Stick Length |
3200 mm |
| Engine Model |
CAT C9 ACERT, 6-cylinder water-cooled electronic injection |
| Displacement |
8.8 L |
| Bore × Stroke |
112 mm × 149 mm |
| Rated Net Power (ISO9249) |
209 kW (280 hp) @1800 rpm |
| Emission Standard |
US Tier3 / EU Stage IIIA |
| Main Pump Max Flow |
290 L/min |
| Main System Relief Pressure |
35 MPa |
| Swing Circuit Pressure |
29.8 MPa |
| Swing Speed |
8.7 rpm |
| Swing Torque |
122 kN·m |
| Max Traction Force |
318 kN |
| Travel Speed |
3.1 / 5.0 km/h (low / high) |
| Gradeability |
70% (35°) |
| Bucket Digging Force |
238 kN |
| Stick Digging Force |
190 kN |
| Max Digging Reach at Ground Level |
11780 mm |
| Max Digging Depth |
8420 mm |
| Max Vertical Digging Depth |
6450 mm |
| Max Dumping Height |
7860 mm |
| Max Digging Height |
10920 mm |
| Overall Transport Length |
11460 mm |
| Overall Transport Width |
3340 mm (600mm track shoe) |
| Overall Transport Height |
3720 mm |
| Cab Height |
3180 mm |
| Tail Swing Radius |
3510 mm |
| Minimum Ground Clearance |
520 mm |
| Track Contact Length |
4720 mm |
| Track Gauge |
2740 mm |
| Counterweight Clearance |
1260 mm |
| Fuel Tank Capacity |
640 L |
| Hydraulic Tank Capacity |
180 L |
| Total Hydraulic System Volume |
430 L |
| Engine Oil Capacity |
41 L |
| Cooling System Capacity |
42 L |
| Swing Reducer Oil |
13 L |
| Final Drive Oil (each side) |
9 L |
