| Operating Weight |
329D: 27600 kg |
| Standard Bucket Capacity |
1.1 ~ 1.3 m³; Rock bucket optional 1.0 m³ |
| Boom Length |
6150 mm |
| Stick Length |
3200 mm |
| Engine Model |
CAT C7 ACERT, 6-cylinder water-cooled direct injection |
| Displacement |
7.2 L |
| Bore × Stroke |
110 mm × 127 mm |
| Rated Net Power (ISO9249) |
152 kW (204 hp) @1800 rpm |
| Emission Standard |
EU Stage IIIA / US Tier3 |
| Main Pump Max Flow |
235 L/min |
| Main System Relief Pressure |
35 MPa |
| Swing Circuit Pressure |
27.5 MPa |
| Swing Speed |
10.2 rpm |
| Swing Torque |
88.0 kN·m |
| Max Traction Force |
265 kN |
| Travel Speed |
3.5 / 5.3 km/h (low / high) |
| Gradeability |
70% (35°) |
| Bucket Digging Force |
190 kN |
| Stick Digging Force |
142 kN |
| Max Digging Reach at Ground Level |
11100 mm |
| Max Digging Depth |
7430 mm |
| Max Vertical Digging Depth |
6420 mm |
| Max Dumping Height |
7350 mm |
| Max Digging Height |
10200 mm |
| Overall Transport Length |
10410 mm |
| Overall Transport Width |
2990 mm (600mm track shoe) |
| Overall Transport Height |
3180 mm |
| Cab Height |
3040 mm |
| Tail Swing Radius |
3100 mm |
| Minimum Ground Clearance |
490 mm |
| Track Contact Length |
4060 mm |
| Total Track Length |
4920 mm |
| Track Gauge |
2390 mm |
| Counterweight Clearance |
1130 mm |
| Fuel Tank Capacity |
605 L |
| Hydraulic Tank Capacity |
170 L |
| Total Hydraulic System Volume |
310 L |
| Engine Oil Capacity |
30 L |
| Cooling System Capacity |
30 L |
| Swing Reducer Oil |
10 L |
| Final Drive Oil (each side) |
6 L |
