| General Information |
Model |
350D |
|
|
Operating Weight |
35,200 kg |
Standard configuration |
|
Bucket Capacity |
1.6 – 2.0 m³ |
Common configuration approx. 1.8 m³ |
|
Engine Model |
Isuzu AH-6HK1X |
|
| Engine System |
Type |
In-line 6-cylinder, Water-cooled, Turbocharged |
|
|
Displacement |
7.79 L |
|
|
Rated Power/Speed |
194 kW / 1,950 rpm |
Approx. 260 HP |
|
Emission Standard |
Meets China National III |
|
| Dimensions |
Transport Length |
10,980 mm |
Includes bucket and boom |
|
Transport Width |
3,190 mm |
600mm track shoe width |
|
Transport Height |
3,350 mm |
To top of cab |
|
Track Length |
5,240 mm |
|
|
Ground Clearance |
500 mm |
|
| Hydraulic System |
Main Pump Type |
Variable Displacement Axial Piston Pump |
|
|
Main System Working Pressure |
34.3 MPa |
|
|
Arm Digging Force |
158 kN |
|
|
Bucket Digging Force |
218 kN |
|
|
Max. Swing Speed |
9.5 rpm |
