| General Information |
Model |
140LC-8 |
LC = Long Crawler |
|
Operating Weight |
14,200 kg |
Standard configuration |
|
Bucket Capacity |
0.15 – 0.65 m³ |
Common configuration approx. 0.52 m³ |
|
Engine Model |
Isuzu GH-4JJ1 |
|
| Engine System |
Type |
In-line 4-cylinder, Water-cooled, Turbocharged |
|
|
Displacement |
4.0 L |
|
|
Rated Power/Speed |
85 kW / 2,000 rpm |
Approx. 114 HP |
|
Emission Standard |
Meets China National III |
|
| Dimensions |
Transport Length |
8,950 mm |
Includes bucket and boom |
|
Transport Width |
2,800 mm |
600mm track shoe width |
|
Transport Height |
2,980 mm |
To top of cab |
|
Track Length |
4,320 mm |
|
|
Ground Clearance |
450 mm |
|
| Hydraulic System |
Main Pump Type |
Variable Displacement Axial Piston Pump |
|
|
Main System Working Pressure |
34.3 MPa |
|
|
Arm Digging Force |
68 kN |
|
|
Bucket Digging Force |
92 kN |
|
|
Max. Swing Speed |
12.0 rpm |
