| General Information |
Model |
125 |
|
|
Operating Weight |
12,800 kg |
Standard configuration |
|
Bucket Capacity |
0.10 – 0.60 m³ |
Common configuration approx. 0.48 m³ |
|
Engine Model |
Isuzu GH-4JJ1 |
|
| Engine System |
Type |
In-line 4-cylinder, Water-cooled, Turbocharged |
|
|
Displacement |
4.0 L |
|
|
Rated Power/Speed |
82 kW / 2,000 rpm |
Approx. 110 HP |
|
Emission Standard |
Meets China National IV |
|
| Dimensions |
Transport Length |
8,450 mm |
Includes bucket and boom |
|
Transport Width |
2,800 mm |
500mm track shoe width |
|
Transport Height |
2,950 mm |
To top of cab |
|
Track Length |
4,120 mm |
|
|
Ground Clearance |
440 mm |
|
| Hydraulic System |
Main Pump Type |
Variable Displacement Axial Piston Pump |
|
|
Main System Working Pressure |
34.3 MPa |
|
|
Arm Digging Force |
62 kN |
|
|
Bucket Digging Force |
85 kN |
|
|
Max. Swing Speed |
12.5 rpm |
