| General Information |
Model |
DX75 |
|
|
Operating Weight |
7,200 kg |
Standard configuration |
|
Bucket Capacity |
0.04 – 0.30 m³ |
Common configuration approx. 0.23 m³ |
|
Engine Model |
Doosan D34NAP |
|
| Engine System |
Type |
In-line 4-cylinder, Water-cooled, Turbocharged |
|
|
Displacement |
3.4 L |
|
|
Rated Power/Speed |
55.4 kW / 2,200 rpm |
Approx. 74 HP |
|
Emission Standard |
Meets China National IV |
|
| Dimensions |
Transport Length |
6,570 mm |
Includes bucket and boom |
|
Transport Width |
2,320 mm |
500mm track shoe width |
|
Transport Height |
2,620 mm |
To top of cab |
|
Track Length |
3,450 mm |
|
|
Ground Clearance |
400 mm |
|
| Hydraulic System |
Main Pump Type |
Variable Displacement Axial Piston Pump |
|
|
Main System Working Pressure |
34.3 MPa |
|
|
Arm Digging Force |
38 kN |
|
|
Bucket Digging Force |
52 kN |
|
|
Max. Swing Speed |
12.0 rpm |
