| General Information |
Model |
DH225-7 |
|
|
Operating Weight |
22,500 kg |
Standard configuration |
|
Bucket Capacity |
0.8 – 1.2 m³ |
Common configuration approx. 1.0 m³ |
|
Engine Model |
Doosan DB58T |
|
| Engine System |
Type |
In-line 6-cylinder, Water-cooled, Turbocharged |
|
|
Displacement |
5.8 L |
|
|
Rated Power/Speed |
125 kW / 2,000 rpm |
Approx. 168 HP |
|
Emission Standard |
Meets China National III |
|
| Dimensions |
Transport Length |
9,670 mm |
Includes bucket and boom |
|
Transport Width |
2,990 mm |
600mm track shoe width |
|
Transport Height |
3,050 mm |
To top of cab |
|
Track Length |
4,570 mm |
|
|
Ground Clearance |
460 mm |
|
| Hydraulic System |
Main Pump Type |
Variable Displacement Axial Piston Pump |
|
|
Main System Working Pressure |
34.3 MPa |
|
|
Arm Digging Force |
103 kN |
|
|
Bucket Digging Force |
142 kN |
|
|
Max. Swing Speed |
11.8 rpm |
