Caterpillar D5 Bulldozer Technical Specifications Table
|
| Parameter Category |
Specification Item |
Detailed Parameters |
Notes/Remarks |
| General Information |
Model |
D5 |
|
|
Operating Weight |
18,500 kg |
With Power Angle Tilt blade |
|
Engine Model |
Cat C7.1 |
|
| Engine System |
Type |
In-line 6-cylinder, Turbocharged Aftercooled |
|
|
Displacement |
7.2 L |
|
|
Rated Power/Speed |
157 kW / 2,000 rpm |
Approx. 211 HP |
|
Peak Torque |
950 N.m |
1,400 rpm |
|
Emission Standard |
Meets China National IV/EU Stage V |
SCR technology |
| Dimensions |
Overall Length |
5,260 mm |
Without ripper |
|
Overall Width |
3,410 mm |
|
|
Overall Height |
3,330 mm |
To top of exhaust |
| Hydraulic System |
Type |
Pilot Hydraulic Control |
|
|
Main System Pressure |
24.1 MPa |
|
|
Steering Pressure |
34.5 MPa |
|
|
Hydraulic Oil Capacity |
98 L |
|
