Caterpillar 329D2 L Hydraulic Excavator Technical Specifications Table
|
| Parameter Category |
Specification Item |
Detailed Parameters |
Notes/Remarks |
| General Information |
Model |
329D2 L |
|
| Operating Weight |
31,500 – 33,200 kg |
Varies with configuration |
| Bucket Capacity |
1.40 – 1.90 m³ |
Common configuration approx. 1.65 m³ |
| Engine Model |
Cat C7.1 ACERT |
|
| Engine System |
Type |
In-line 6-cylinder, Water-cooled, Turbocharged |
Electronic Control |
| Displacement |
7.2 L |
|
| Rated Power/Speed |
179 kW / 1,800 rpm |
Approx. 240 HP |
| Emission Standard |
Meets China National III/EU Stage IIIA |
|
| Hydraulic System |
Main Pump Type |
Variable Displacement Axial Piston Pump |
|
| Main System Working Pressure |
34.8 MPa |
|
| Arm Digging Force |
146 kN |
|
| Bucket Digging Force |
201 kN |
|
| Max. Swing Speed |
9.5 rpm |
|
| Dimensions |
Transport Length |
11,085 mm |
Includes bucket and boom |
| Transport Width |
3,190 mm |
600mm track shoe width |
| Transport Height |
3,345 mm |
To top of cab |
