| Model |
CAT 320E / 320EL |
| Machine Type |
Medium Crawler Hydraulic Excavator |
| Operating Weight |
21700 kg (47840 lbs) |
| Engine Model |
Cat C6.6 ACERT, inline 6-cylinder, turbocharged, electronic injection |
| Rated Net Power (ISO 9249) |
114 kW (153 hp) @2000 rpm |
| Gross Power |
122 kW (164 hp) @2000 rpm |
| Displacement |
6.6 L (403 cu in) |
| Bore × Stroke |
105 mm × 127 mm |
| Emission Standard |
US EPA Tier 4 Interim |
| Standard Bucket Capacity |
1.19 m³ (1.56 yd³) |
| Boom Length |
5700 mm |
| Stick Length |
2900 mm |
| Max Digging Depth |
6720 mm (22.05 ft) |
| Max Reach at Ground Level |
9760 mm (32.02 ft) |
| Max Dumping Height |
6590 mm (21.62 ft) |
| Bucket Digging Force (ISO) |
151 kN |
| Arm Digging Force (ISO) |
115 kN |
| Max Hydraulic Pump Flow (2 main pumps) |
222 L/min (58.6 US gal/min) |
| Main Hydraulic Pressure |
35 MPa (5076 psi) |
| Swing Speed |
11.2 rpm |
| Swing Torque |
61.8 kN·m |
| Travel Speed |
3.2 ~ 5.6 km/h (1.99 ~ 3.48 mph) |
| Max Drawbar Pull |
205 kN |
| Fuel Tank Capacity |
290 L (76.6 US gal) |
| Hydraulic Tank Capacity |
143 L |
| Transport Length |
9520 mm (31.23 ft) |
| Transport Width |
2590 mm (8.50 ft) |
| Transport Height |
3010 mm (9.88 ft) |
| Standard Track Shoe Width |
600 mm (23.62 in) |
| Rear Swing Radius |
2830 mm |
| Min Ground Clearance |
470 mm |
