| Caterpillar 320D2 L Hydraulic Excavator Technical Specifications Table | |||
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
| General Information | Model | 320D2 L | |
| Operating Weight | 21,200 – 22,500 kg | Varies with configuration | |
| Bucket Capacity | 0.85 – 1.20 m³ | Common configuration approx. 1.0 m³ | |
| Engine Model | Cat C4.4 | ||
| Engine System | Type | In-line 4-cylinder, Water-cooled, Turbocharged | |
| Displacement | 4.4 L | ||
| Rated Power/Speed | 103 kW / 1,800 rpm | Approx. 138 HP | |
| Emission Standard | Meets China National III/EU Stage IIIA | ||
| Hydraulic System | Main Pump Type | Variable Displacement Axial Piston Pump | |
| Main System Working Pressure | 34.8 MPa | ||
| Arm Digging Force | 78 kN | ||
| Bucket Digging Force | 108 kN | ||
| Max. Swing Speed | 11.8 rpm | ||
| Dimensions | Transport Length | 9,690 mm | Includes bucket and boom |
| Transport Width | 2,800 mm | 600mm track shoe width | |
| Transport Height | 3,090 mm | To top of cab | |
