| Brand | Volvo |
| Model | Volvo EC120D |
| Year | 2017 |
| Working time | 6624 |
| Origin | Sweden |
| Engine Power | 82KW/ 110HP |
Volvo EC120D Crawler Excavator Technical Specifications Table
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
|---|---|---|---|
| General Information | Model | EC120D | |
| Operating Weight | 12,800 kg | Standard configuration | |
| Bucket Capacity | 0.10 – 0.60 m³ | Common configuration approx. 0.48 m³ | |
| Engine Model | Volvo D3J | ||
| Engine System | Type | In-line 4-cylinder, Water-cooled, Turbocharged | |
| Displacement | 3.6 L | ||
| Rated Power/Speed | 82 kW / 2,000 rpm | Approx. 110 HP | |
| Emission Standard | Meets China National IV | ||
| Dimensions | Transport Length | 8,450 mm | Includes bucket and boom |
| Transport Width | 2,800 mm | 500mm track shoe width | |
| Transport Height | 2,950 mm | To top of cab | |
| Track Length | 4,120 mm | ||
| Ground Clearance | 440 mm | ||
| Hydraulic System | Main Pump Type | Variable Displacement Axial Piston Pump | |
| Main System Working Pressure | 34.3 MPa | ||
| Arm Digging Force | 62 kN | ||
| Bucket Digging Force | 85 kN | ||
| Max. Swing Speed | 12.5 rpm |
