| Brand | Shantui |
| Model | Shantui SD22 |
| Year | 2024 |
| Working time | 761 |
| Origin | China |
| Engine Power | 162KW/ 217HP |
Shantui SD22 Bulldozer Technical Specifications Table
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
|---|---|---|---|
| General Information | Model | SD22 | |
| Operating Weight | 16,800 kg | Standard configuration | |
| Engine Model | Shangchai D6114 | ||
| Engine System | Type | In-line 6-cylinder, Water-cooled | |
| Displacement | 8.27 L | ||
| Rated Power/Speed | 162 kW / 1,850 rpm | Approx. 217 HP | |
| Emission Standard | Meets China National II | ||
| Dimensions | Overall Length | 5,130 mm | Without ripper |
| Overall Width | 3,775 mm | ||
| Overall Height | 3,100 mm | To top of exhaust | |
| Track Length | 2,740 mm | ||
| Shoe Width | 510 mm | Standard | |
| Ground Clearance | 400 mm | ||
| Equipment | Blade | ||
| Blade Capacity | 4.3 m³ | Straight tilt blade | |
| Blade Width | 3,775 mm | ||
| Blade Height | 1,100 mm | ||
| Hydraulic System | |||
| Working Pressure | 14 MPa | ||
| Hydraulic Oil Capacity | 120 L | ||
| Transmission | Type | Mechanical shift | |
| Forward Speeds | 5 | ||
| Reverse Speeds | 4 | ||
| Max Drawbar Pull | 188 kN | ||
| Performance | Travel Speed | 3.6-10.2 km/h | Forward |
| Gradeability | 30° | ||
| Ground Pressure | 68 kPa |
