$13,000.00

Brand Doosan
Model Doosan 60
Year 2024
Working time 337 hrs
Origin Korea
Engine Power 44.5KW/ 59.7HP
Inquiry Now
Category: Tags: , Brand:

Doosan 60 Wheeled Excavator Technical Specifications Table

Parameter Category Specification Item Detailed Parameters Notes/Remarks
General Information Model 60
Operating Weight 5,800 kg Standard configuration
Bucket Capacity 0.04 – 0.28 m³ Common configuration approx. 0.20 m³
Engine Model Doosan D24NAP
Engine System Type In-line 4-cylinder, Water-cooled, Turbocharged
Displacement 2.4 L
Rated Power/Speed 44.5 kW / 2,200 rpm Approx. 59.7 HP
Emission Standard Meets China National IV
Dimensions Overall Length 6,150 mm Working condition
Overall Width 2,100 mm
Overall Height 2,750 mm To top of cab
Wheelbase 2,400 mm
Wheel Track 1,650 mm
Ground Clearance 280 mm
Hydraulic System Main Pump Type Variable Displacement Axial Piston Pump
Main System Working Pressure 31.4 MPa
Arm Digging Force 28 kN
Bucket Digging Force 38 kN
Max. Swing Speed 13.5 rpm
