| Brand | Caterpillar(Cat) |
| Model | Cat D6R |
| Year | 2022 |
| Working time | 2652 |
| Origin | Japan |
| Engine Power | 157KW/ 210HP |
Caterpillar D6R Bulldozer Technical Specifications Table
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
|---|---|---|---|
| General Information | Model | D6R | |
| Operating Weight | 20,300 kg | Standard configuration | |
| Engine Model | Cat C9 | ||
| Engine System | Type | In-line 6-cylinder, Turbocharged, Aftercooled | |
| Displacement | 8.8 L | ||
| Rated Power/Speed | 157 kW / 2,000 rpm | Approx. 210 HP | |
| Emission Standard | Meets China National III | ||
| Dimensions | Overall Length | 5,260 mm | Without ripper |
| Overall Width | 3,410 mm | ||
| Overall Height | 3,330 mm | To top of exhaust | |
| Track Length | 2,870 mm | ||
| Shoe Width | 560 mm | Standard | |
| Ground Clearance | 400 mm | ||
| Equipment | Blade | ||
| Blade Capacity | 3.8 m³ | PAT blade | |
| Blade Width | 3,410 mm | ||
| Blade Height | 1,065 mm | ||
| Hydraulic System | |||
| Working Pressure | 24,100 kPa | ||
| Hydraulic Oil Capacity | 132 L | ||
| Transmission | Type | Powershift Transmission | |
| Forward Speeds | 3 | ||
| Reverse Speeds | 3 | ||
| Max Drawbar Pull | 245 kN | ||
| Performance | Travel Speed | 0-11.3 km/h | Forward |
| Gradeability | 30° | ||
| Ground Pressure | 72 kPa |
