| Brand | Caterpillar(Cat) |
| Model | Cat D6G |
| Year | 2024 |
| Working time | 673 |
| Origin | Japan |
| Engine Power | 119KW/ 160HP |
Caterpillar D6G Bulldozer Technical Specifications Table
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
|---|---|---|---|
| General Information | Model | D6G | |
| Operating Weight | 18,500 kg | Standard configuration | |
| Engine Model | Cat 3306 | ||
| Engine System | Type | In-line 6-cylinder, Turbocharged | |
| Displacement | 10.5 L | ||
| Rated Power/Speed | 119 kW / 1,800 rpm | Approx. 160 HP | |
| Emission Standard | Meets China National II | ||
| Dimensions | Overall Length | 4,850 mm | Without ripper |
| Overall Width | 2,690 mm | ||
| Overall Height | 3,230 mm | To top of exhaust | |
| Track Length | 2,870 mm | ||
| Shoe Width | 510 mm | Standard | |
| Ground Clearance | 400 mm | ||
| Equipment | Blade | ||
| Blade Capacity | 3.2 m³ | Straight tilt blade | |
| Blade Width | 3,690 mm | ||
| Blade Height | 1,130 mm | ||
| Hydraulic System | |||
| Working Pressure | 17,500 kPa | ||
| Hydraulic Oil Capacity | 98 L | ||
| Transmission | Type | Powershift Transmission | |
| Forward Speeds | 3 | ||
| Reverse Speeds | 3 | ||
| Max Drawbar Pull | 188 kN | ||
| Performance | Travel Speed | 0-11.2 km/h | Forward |
| Gradeability | 30° | ||
| Ground Pressure | 68 kPa |
