Caterpillar 355 Hydraulic Excavator Technical Specifications Table |
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
| General Information | Model | 355 | |
| Operating Weight | 55,600 kg | Standard configuration |
| Bucket Capacity | 2.3 – 3.1 m³ | Common configuration approx. 2.7 m³ |
| Engine Model | Cat C13 | |
| Engine System | Type | In-line 6-cylinder, Water-cooled, Turbocharged | |
| Displacement | 12.5 L | |
| Rated Power/Speed | 287 kW / 1,800 rpm | Approx. 385 HP |
| Emission Standard | Meets China National III/EU Stage IIIA | |
| Dimensions | Transport Length | 12,150 mm | Includes bucket and boom |
| Transport Width | 3,760 mm | 800mm track shoe width |
| Transport Height | 3,760 mm | To top of cab |
| Hydraulic System | Main Pump Type | Variable Displacement Axial Piston Pump | |
| Main System Working Pressure | 34.8 MPa | |
| Arm Digging Force | 245 kN | |
| Bucket Digging Force | 324 kN | |
| Max. Swing Speed | 7.8 rpm | |
