| Brand | Volvo |
| Model | Volvo EC350 |
| Year | 2023 |
| Working time | 326 |
| Origin | Korea |
| Engine Power | 212KW/ 284HP |
Volvo EC350 Crawler Excavator Technical Specifications Table
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
|---|---|---|---|
| General Information | Model | EC350 | |
| Operating Weight | 35,200 kg | Standard configuration | |
| Bucket Capacity | 1.6 – 2.0 m³ | Common configuration approx. 1.8 m³ | |
| Engine Model | Volvo D8E | ||
| Engine System | Type | In-line 6-cylinder, Water-cooled, Turbocharged | |
| Displacement | 8.1 L | ||
| Rated Power/Speed | 212 kW / 1,800 rpm | Approx. 284 HP | |
| Emission Standard | Meets China National IV | ||
| Dimensions | Transport Length | 10,980 mm | Includes bucket and boom |
| Transport Width | 3,190 mm | 600mm track shoe width | |
| Transport Height | 3,350 mm | To top of cab | |
| Track Length | 5,240 mm | ||
| Ground Clearance | 500 mm | ||
| Hydraulic System | Main Pump Type | Variable Displacement Axial Piston Pump | |
| Main System Working Pressure | 34.3 MPa | ||
| Arm Digging Force | 158 kN | ||
| Bucket Digging Force | 218 kN | ||
| Max. Swing Speed | 9.5 rpm |
