Komatsu 30 Series Forklift Technical Specifications Table
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
|---|---|---|---|
| General Information | Model | FB30 | 3.0 ton |
| Rated Load Capacity | 3,000 kg | ||
| Load Center | 500 mm | ||
| Operation Type | Sit-down | ||
| Power System | Power Type | Diesel | |
| Engine Model | Komatsu S4D | ||
| Engine Type | In-line 4-cylinder, Water-cooled | ||
| Displacement | 2.2 L | ||
| Rated Power | 46 kW | Approx. 62 HP | |
| Emission Standard | Meets China National IV | ||
| Dimensions | Overall Length | 3,745 mm | With forks |
| Overall Width | 1,590 mm | ||
| Overall Height | 2,190 mm | Overhead guard height | |
| Wheelbase | 1,700 mm | ||
| Min Turning Radius | 2,400 mm | ||
| Performance | Lift Height | 3,000 mm | |
| Free Lift | 150 mm | ||
| Lift Speed | 520 mm/s | Unloaded | |
| Lowering Speed | 480 mm/s | Unloaded | |
| Travel Speed | 20 km/h | Unloaded | |
| Gradeability | 21% | ||
| Tire System | Front Tire | 28×9-15-12PR | Solid |
| Rear Tire | 6.50-10-10PR | Solid |
