Brand Kobelco
Model Kobelco 75
Year 2023
Working time 521
Origin Japan
Engine Power 55.4KW/ 74HP
Inquiry Now
Category: Brand:

Kobelco 75 Crawler Excavator Technical Specifications Table

Parameter Category Specification Item Detailed Parameters Notes/Remarks
General Information Model 75
Operating Weight 7,200 kg Standard configuration
Bucket Capacity 0.04 – 0.28 m³ Common configuration approx. 0.22 m³
Engine Model Yanmar 4TNV98T
Engine System Type In-line 4-cylinder, Water-cooled, Turbocharged
Displacement 3.3 L
Rated Power/Speed 55.4 kW / 2,200 rpm Approx. 74 HP
Emission Standard Meets China National IV
Dimensions Transport Length 6,570 mm Includes bucket and boom
Transport Width 2,320 mm 500mm track shoe width
Transport Height 2,620 mm To top of cab
Track Length 3,450 mm
Ground Clearance 400 mm
Hydraulic System Main Pump Type Variable Displacement Axial Piston Pump
Main System Working Pressure 34.3 MPa
Arm Digging Force 38 kN
Bucket Digging Force 52 kN
Max. Swing Speed 12.0 rpm
