Brand Kobelco
Model Kobelco 55CR
Year 2023
Working time 752
Origin Japan
Engine Power 49.6KW/ 66HP
Inquiry Now
Category: Brand:

Kobelco 55CR Crawler Excavator Technical Specifications Table

Parameter Category Specification Item Detailed Parameters Notes/Remarks
General Information Model 55CR CR = Compact Radius
Operating Weight 5,500 kg Standard configuration
Bucket Capacity 0.03 – 0.12 m³ Common configuration approx. 0.08 m³
Engine Model Yanmar 4TNV98T
Engine System Type In-line 4-cylinder, Water-cooled, Turbocharged
Displacement 3.3 L
Rated Power/Speed 49.5 kW / 2,200 rpm Approx. 66 HP
Emission Standard Meets China National IV
Dimensions Transport Length 5,890 mm Includes bucket and boom
Transport Width 1,990 mm 450mm track shoe width
Transport Height 2,580 mm To top of cab
Track Length 2,780 mm
Ground Clearance 320 mm
Hydraulic System Main Pump Type Variable Displacement Axial Piston Pump
Main System Working Pressure 34.3 MPa
Arm Digging Force 28 kN
Bucket Digging Force 39 kN
Max. Swing Speed 14.5 rpm
