$13,000.00

Brand Hyundai
Model Hyundai 110VS
Year 2018
Working time 5790
Origin Korea
Engine Power 77KW/ 99HP
Inquiry Now
Category: Brand:

Hyundai 110VS Crawler Excavator Technical Specifications Table

Parameter Category Specification Item Detailed Parameters Notes/Remarks
General Information Model 110VS
Operating Weight 11,200 kg Standard configuration
Bucket Capacity 0.04 – 0.45 m³ Common configuration approx. 0.38 m³
Engine Model Cummins B3.9
Engine System Type In-line 4-cylinder, Water-cooled, Turbocharged
Displacement 3.9 L
Rated Power/Speed 74 kW / 2,200 rpm Approx. 99 HP
Emission Standard Meets China National III
Dimensions Transport Length 8,120 mm Includes bucket and boom
Transport Width 2,800 mm 500mm track shoe width
Transport Height 2,890 mm To top of cab
Track Length 3,980 mm
Ground Clearance 420 mm
Hydraulic System Main Pump Type Variable Displacement Axial Piston Pump
Main System Working Pressure 34.3 MPa
Arm Digging Force 52 kN
Bucket Digging Force 71 kN
Max. Swing Speed 12.8 rpm
