$46,000.00

Brand Doosan
Model Doosan DX340LCA
Year 2022
Working time 2474 hrs
Origin Korea
Engine Power 194KW/ 260HP
Inquiry Now
Category: Brand:

Doosan DX340LCA Crawler Excavator Technical Specifications Table

Parameter Category Specification Item Detailed Parameters Notes/Remarks
General Information Model 340LCA
Operating Weight 34,500 kg Standard configuration
Bucket Capacity 1.5 – 2.0 m³ Common configuration approx. 1.7 m³
Engine Model Cummins M11-C
Engine System Type In-line 6-cylinder, Water-cooled, Turbocharged
Displacement 10.8 L
Rated Power/Speed 194 kW / 2,000 rpm Approx. 260 HP
Emission Standard Meets China National II
Dimensions Transport Length 11,250 mm Includes bucket and boom
Transport Width 3,490 mm 700mm track shoe width
Transport Height 3,450 mm To top of cab
Track Length 5,420 mm
Ground Clearance 520 mm
Hydraulic System Main Pump Type Dual Variable Displacement Axial Piston Pumps
Main System Working Pressure 34.3 MPa
Arm Digging Force 168 kN
Bucket Digging Force 232 kN
Max. Swing Speed 9.5 rpm
