$26,000.00

Brand Doosan
Model Doosan DH370LC-9
Year 2018
Working time 7193 hrs
Origin Korea
Engine Power 224kW / 300 HP
Inquiry Now
Category: Brand:

Doosan DH370LC-9 Crawler Excavator Technical Specifications Table

Parameter Category Specification Item Detailed Parameters Notes/Remarks
General Information Model DH370-9C
Operating Weight 37,500 kg Standard configuration
Bucket Capacity 1.7 – 2.2 m³ Common configuration approx. 1.9 m³
Engine Model Cummins QSB6.7
Engine System Type In-line 6-cylinder, Water-cooled, Turbocharged, Electronic Control
Displacement 6.7 L
Rated Power/Speed 224 kW / 2,000 rpm Approx. 300 HP
Emission Standard Meets China National III
Dimensions Transport Length 11,580 mm Includes bucket and boom
Transport Width 3,490 mm 700mm track shoe width
Transport Height 3,520 mm To top of cab
Track Length 5,740 mm
Ground Clearance 540 mm
Hydraulic System Main Pump Type Dual Variable Displacement Axial Piston Pumps
Main System Working Pressure 34.3 MPa
Arm Digging Force 192 kN
Bucket Digging Force 265 kN
Max. Swing Speed 8.8 rpm
