| Brand | Caterpillar(Cat) |
| Model | Cat D10 |
| Year | 2021 |
| Working time | 3512 |
| Origin | Japan |
| Engine Power | 485KW/ 650HP |
Caterpillar D10 Bulldozer Technical Specifications Table
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
|---|---|---|---|
| General Information | Model | D10 | |
| Operating Weight | 66,040 kg | Standard configuration | |
| Engine Model | Cat 3412 | ||
| Engine System | Type | V12, Diesel Engine | |
| Displacement | 27.0 L | ||
| Rated Power/Speed | 485 kW / 1,800 rpm | Approx. 650 HP | |
| Peak Torque | 2,880 N·m | ||
| Emission Standard | Meets China National II | ||
| Dimensions | Overall Length | 7,620 mm | Without ripper |
| Overall Width | 4,115 mm | ||
| Overall Height | 4,445 mm | To top of exhaust | |
| Track Length | 3,430 mm | ||
| Shoe Width | 610 mm | Standard | |
| Ground Clearance | 565 mm | ||
| Equipment | Blade | ||
| Blade Capacity | 13.2 m³ | SU blade | |
| Blade Width | 4,115 mm | ||
| Blade Height | 1,735 mm | ||
| Hydraulic System | |||
| Working Pressure | 24.1 MPa | ||
| Hydraulic Oil Capacity | 341 L | ||
| Transmission | Type | Powershift Transmission | |
| Forward Speeds | 3 | ||
| Reverse Speeds | 3 | ||
| Max Drawbar Pull | 1,200 kN | ||
| Performance | Travel Speed | 0-11.3 km/h | Forward |
| Gradeability | 30° | ||
| Ground Pressure | 124 kPa |
