Caterpillar 340D2 L Hydraulic Excavator Technical Specifications Table |
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
| General Information | Model | 340D2 L | |
| Operating Weight | 41,200 – 43,500 kg | Varies with configuration |
| Bucket Capacity | 1.80 – 2.30 m³ | Common configuration approx. 2.0 m³ |
| Engine Model | Cat C9 ACERT | |
| Engine System | Type | In-line 6-cylinder, Water-cooled, Turbocharged | |
| Displacement | 9.3 L | |
| Rated Power/Speed | 224 kW / 1,800 rpm | Approx. 300 HP |
| Emission Standard | Meets China National III/EU Stage IIIA | |
| Dimensions | Transport Length | 11,345 mm | Includes bucket and boom |
| Transport Width | 3,490 mm | 700mm track shoe width |
| Transport Height | 3,565 mm | To top of cab |
| Hydraulic System | Main Pump Type | Variable Displacement Axial Piston Pump | |
| Main System Working Pressure | 34.8 MPa | |
| Arm Digging Force | 178 kN | |
| Bucket Digging Force | 245 kN | |
| Max. Swing Speed | 8.5 rpm | |
