Caterpillar 325D Hydraulic Excavator Technical Specifications Table |
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
| General Information | Model | 325D | |
| Operating Weight | 28,600 – 30,500 kg | Varies with configuration |
| Bucket Capacity | 1.30 – 1.80 m³ | Common configuration approx. 1.45 m³ |
| Engine Model | Cat C7 ACERT | |
| Engine System | Type | In-line 6-cylinder, Water-cooled, Turbocharged | |
| Displacement | 7.2 L | |
| Rated Power/Speed | 167 kW / 1,800 rpm | Approx. 224 HP |
| Emission Standard | Meets China National III/EU Stage IIIA | |
| Hydraulic System | Main Pump Type | Variable Displacement Axial Piston Pump | |
| Main System Working Pressure | 34.8 MPa | |
| Arm Digging Force | 128 kN | |
| Bucket Digging Force | 176 kN | |
| Max. Swing Speed | 9.8 rpm | |
| Dimensions | Transport Length | 10,620 mm | Includes bucket and boom |
| Transport Width | 3,190 mm | 600mm track shoe width |
| Transport Height | 3,270 mm | To top of cab |
