Caterpillar 323 GC Hydraulic Excavator Technical Specifications Table |
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
| General Information | Model | 323 GC | GC = General Construction |
| Operating Weight | 23,700 kg | Standard configuration |
| Bucket Capacity | 0.65 – 1.26 m³ | Common configuration approx. 1.05 m³ |
| Engine Model | Cat C7.1 | |
| Engine System | Type | In-line 6-cylinder, Water-cooled, Turbocharged | |
| Displacement | 7.2 L | |
| Rated Power/Speed | 159 kW / 1,800 rpm | Approx. 213 HP |
| Emission Standard | Meets China National IV/EU Stage V | SCR technology |
| Dimensions | Transport Length | 9,955 mm | Includes bucket and boom |
| Transport Width | 3,190 mm | 600mm track shoe width |
| Transport Height | 3,250 mm | To top of cab |
| Hydraulic System | Main Pump Type | Variable Displacement Axial Piston Pump | |
| Main System Working Pressure | 35.0 MPa | |
| Arm Digging Force | 108 kN | |
| Bucket Digging Force | 149 kN | |
| Max. Swing Speed | 10.2 rpm | |
