| Caterpillar 320D2 L Technical Specifications Table |
| Parameter Category | Item | Specification | Notes / Explanation |
| Basic Information | Model | 320D2 L | |
| Operating Weight | 21,200 kg – 21,800 kg | Varies by configuration |
| Bucket Capacity | 0.60 – 1.25 m³ | Common configuration ~0.9 – 1.0 m³ |
| Engine | Model | Caterpillar C6.4 ACERT | |
| Type | Turbocharged, Aftercooled, Electronically Controlled Diesel Engine | |
| Rated Power | 103 kW / 138 HP | |
| Displacement | 6.4 L | |
| Emission Standard | Meets Tier 3 / EU Stage IIIA | |
| Hydraulic System | Hydraulic System Type | Load Sensing System | |
| Main Pump Type | Variable Displacement Axial Piston Pump | |
| Main Pump Max. Flow | 2 x 202 L/min | |
| Main Relief Valve Pressure | 34.8 MPa | |
| Dimensions | Length | 9,540 mm | |
| Width | 2,800 mm | With 700mm shoe |
| Height | 3,150 mm | To top of cab |
| Distance between track centers | 4,540 mm | |
