Caterpillar 315D2 GC Hydraulic Excavator Technical Specifications Table |
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
| General Information | Model | 315D2 GC | GC = General Construction |
| Operating Weight | 15,800 kg | Standard configuration |
| Bucket Capacity | 0.15 – 0.80 m³ | Common configuration approx. 0.65 m³ |
| Engine Model | Cat C4.4 | |
| Engine System | Type | In-line 4-cylinder, Water-cooled, Turbocharged | |
| Displacement | 4.4 L | |
| Rated Power/Speed | 83 kW / 1,800 rpm | Approx. 111 HP |
| Emission Standard | Meets China National III/EU Stage IIIA | |
| Dimensions | Transport Length | 9,245 mm | Includes bucket and boom |
| Transport Width | 2,800 mm | 600mm track shoe width |
| Transport Height | 2,990 mm | To top of cab |
| Hydraulic System | Main Pump Type | Variable Displacement Axial Piston Pump | |
| Main System Working Pressure | 34.3 MPa | |
| Arm Digging Force | 67 kN | |
| Bucket Digging Force | 91 kN | |
| Max. Swing Speed | 11.5 rpm | |
