$22,200.00

Brand Caterpillar （Cat）
Model Caterpillar 307
Year 2020
Working time 1504 hrs
Origin Japan
Size 6,550 mm×2,320 mm×2,630 mm
Engine Power 42.5 kW / 57HP
Inquiry Now
Category: Tags: , , , ,
Caterpillar 307 Mini Hydraulic Excavator Technical Specifications Table
Parameter Category Specification Item Detailed Parameters Notes/Remarks
General Information Model 307
Operating Weight 7,200 – 7,500 kg Varies with configuration
Bucket Capacity 0.28 – 0.42 m³ Common configuration approx. 0.32 m³
Engine Model Cat C2.6
Engine System Type In-line 4-cylinder, Water-cooled, Turbocharged, Electronic Control
Displacement 2.6 L
Rated Power 42.5 kW / 57 HP
Emission Standard Meets China National IV/EU Stage V DPF aftertreatment technology
Hydraulic System Main Pump Type Variable Displacement Axial Piston Pump
Main System Working Pressure 34.3 MPa
Arm Digging Force 41 kN
Bucket Digging Force 53 kN
Maximum Swing Speed 11.8 rpm
Dimensions Transport Length 6,550 mm Includes bucket and boom
Transport Width 2,320 mm 600mm track shoe width
Transport Height 2,630 mm
