$15,220.00

Brand Caterpillar(Cat)
Model Caterpillar 305.5E2
Year 2023
Working time 798 hrs
Origin Japan
Size 5,890 mm×2,160 mm×2,620 mm
Engine Power 41.5kW / 55.6 HP
Inquiry Now
Category: Tags: ,
Caterpillar 305.5E2 Mini Hydraulic Excavator Technical Specifications Table
Parameter Category Specification Item Detailed Parameters Notes
Basic Information Model 305.5 E2
Bucket Capacity 0.10 – 0.28 m³ Standard is approx. 0.15 m³
Engine Model Cat C2.6
Engine System Type In-line 4-cylinder, Water-cooled, Turbocharged
Displacement 2.6 L
Rated Power / Speed 41.5 kW / 2,200 rpm Approx. 55.6 HP
Emission Standard Meets China National III / EU Stage IIIA
Hydraulic System Main Pump Type Variable Displacement Axial Piston Pump
Main Relief Valve Pressure 34.3 MPa
Pilot System Pressure 3.9 MPa
Dimensions Transport Length 5,890 mm Includes bucket and boom
Transport Width 2,160 mm With 600mm shoe width
Transport Height 2,620 mm To top of cab
