| Brand | Bobcat |
| Model | Bobcat S550 |
| Year | 2018 |
| Working time | 1547 |
| Origin | Korea |
| Engine Power | 85KW/ 114HP |
Bobcat S550 Skid Steer Loader Technical Specifications Table
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
|---|---|---|---|
| General Information | Model | S550 | |
| Operating Weight | 3,800 kg | Standard configuration | |
| Rated Load Capacity | 1,588 kg | ||
| Tip Load | 3,175 kg | ||
| Engine Model | Kubota V3800 | ||
| Engine System | Type | In-line 4-cylinder, Water-cooled, Turbocharged | |
| Displacement | 3.8 L | ||
| Rated Power | 85 kW | Approx. 114 HP | |
| Emission Standard | Meets China National IV | ||
| Dimensions | Overall Length | 4,270 mm | Without attachment |
| Overall Width | 2,290 mm | ||
| Overall Height | 2,290 mm | To top of ROPS | |
| Wheelbase | 1,520 mm | ||
| Ground Clearance | 250 mm | ||
| Hydraulic System | Main Pump Type | Axial Piston Pump | |
| Working Pressure | 24.1 MPa | ||
| Flow Rate | 132 L/min | ||
| Auxiliary Hydraulic Flow | 91 L/min | Optional | |
| Lift Mechanism | |||
| Lift Height | 3,450 mm | To pivot pin | |
| Dump Height | 2,590 mm | ||
| Breakout Force | 3,629 kg | ||
| Lift Capacity | 1,950 kg | To full height |
