| Brand | Bobcat |
| Model | Bobcat S160 |
| Year | 2019 |
| Working time | 932 |
| Origin | Korea |
| Engine Power | 55.4KW/ 74.3HP |
Bobcat S160 Skid Steer Loader Technical Specifications Table
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
|---|---|---|---|
| General Information | Model | S160 | |
| Operating Weight | 2,495 kg | Standard configuration | |
| Rated Load Capacity | 726 kg | ||
| Tip Load | 1,452 kg | ||
| Engine Model | Kubota V2607 | ||
| Engine System | Type | In-line 4-cylinder, Water-cooled, Turbocharged | |
| Displacement | 2.6 L | ||
| Rated Power | 55.4 kW | Approx. 74.3 HP | |
| Emission Standard | Meets China National IV | ||
| Dimensions | Overall Length | 3,480 mm | Without attachment |
| Overall Width | 1,880 mm | ||
| Overall Height | 2,030 mm | To top of ROPS | |
| Wheelbase | 1,270 mm | ||
| Ground Clearance | 210 mm | ||
| Hydraulic System | Main Pump Type | Axial Piston Pump | |
| Working Pressure | 24.1 MPa | ||
| Flow Rate | 91 L/min | ||
| Auxiliary Hydraulic Flow | 53 L/min | Optional | |
| Lift Mechanism | |||
| Lift Height | 2,972 mm | To pivot pin | |
| Dump Height | 2,210 mm | ||
| Breakout Force | 2,245 kg | ||
| Lift Capacity | 1,025 kg | To full height |
