| Brand | Bobcat |
| Model | Bobcat S130 |
| Year | 2019 |
| Working time | 781 |
| Origin | Korea |
| Engine Power | 46.3KW/ 62HP |
Bobcat S130 Skid Steer Loader Technical Specifications Table
| Parameter Category | Specification Item | Detailed Parameters | Notes/Remarks |
|---|---|---|---|
| General Information | Model | S130 | |
| Operating Weight | 1,950 kg | Standard configuration | |
| Rated Load Capacity | 590 kg | ||
| Tip Load | 1,180 kg | ||
| Engine Model | Kubota V2403 | ||
| Engine System | Type | In-line 4-cylinder, Water-cooled | |
| Displacement | 2.43 L | ||
| Rated Power | 46.3 kW | Approx. 62 HP | |
| Emission Standard | Meets China National IV | ||
| Dimensions | Overall Length | 3,020 mm | Without attachment |
| Overall Width | 1,650 mm | ||
| Overall Height | 1,980 mm | To top of ROPS | |
| Wheelbase | 1,120 mm | ||
| Ground Clearance | 180 mm | ||
| Hydraulic System | Main Pump Type | Gear Pump | |
| Working Pressure | 20.7 MPa | ||
| Flow Rate | 68 L/min | ||
| Auxiliary Hydraulic Flow | 45.4 L/min | Optional | |
| Lift Mechanism | |||
| Lift Height | 2,690 mm | To pivot pin | |
| Dump Height | 1,980 mm | ||
| Breakout Force | 1,610 kg | ||
| Lift Capacity | 816 kg | To full height |
